Hikvision
| Software features | |
| Tag | 48 |
| Area | 32 |
| Zones | Up to 96 (including 48 PIRCAMs & 16 onboard Wired Zones & 2 onboard Wired Outputs) |
| Onboard video clips | 4 |
| Installer | 1 |
| User | 46 |
| Admin | 1 |
| Voice Prompt | Supported |
| Loudspeaker built in | Supported |
| Tag reader built in | No |
| Memory Log stored | 5000 |
| Programming tools | Hik-Connect/Hik-ProConnect/Web Portal/ IVMS4200/ Convergence Cloud |
| Firmware upgrade | APP/Web Portal |
| Arm modes | Away/Stay |
| Automatic Arm/Disarm Timers | Supported |
| Forced Arming with Open Zones | Supported |
| Diagnostics via the APP or Web | Supported |
| ARC protocol | SIA DC09(SIA level 2, Contact ID), ISUP, ISAPI (SDK) Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685) Supports video verification and remote control |
| User APP for operating | Supported |
| Installer APP for programming | Supported |
| Web server for maintenance (offline configuration) | Supported |
| Hardware features | |
| Power Output | 2 onboard (12v, total 1A) |
| RS232 output | Supported |
| SIM slot | Dual |
| RF transmission | |
| Two-way Wireless Communication | Support |
| RF Frequency | 868Mhz |
| Wireless Security | Frequency Hoping 128 AES Encryption |
| 3/4G on board | Supported |
| Electrical characteristics | |
| Power supply | Built in power supply |
| Battery type | 12v 7Ah Storage battery (Battery is not included by default) |
| Battery life span | Up to 36 hours at normal temperature (The battery working time can be significantly reduced at low temperatures)(Battery life varies from different battery types) |
| Wireless transmission | |
| Wired network | Supported |
| Wi-Fi Standard | Supported |
| Display | |
| LEDs Status | Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power |
| General | |
| Operation temperature | -10 °C to 40 °C |
| Shell material | Plastic |
| Dimensions (WxHxD) | 261 x 199 x 86.4mm |
| Weight | 1083g (No battery) |
| Colour | White |
| Device management | |
| Keyfob | 48 |
| Wireless sounder | 6 (3 internal+3 External) |
| Keypad | 8 (Including Tag reader) |
| Wireless Repeater | 4 |
| Multi Transmitter | 5 |
| PIR Cam | Supported |
