| Feature |
| Digital Processing | Support |
| Tamper Protection | Front; Rear |
| Environment Temperature Indicator | Support |
| Signal Strength Indicator | Support |
| Interface |
| LED Indicator | Blue (alarm) |
| Transmission |
| Transmission Technology | Tri-X Wireless |
| Transmission Method | Two-Way RF Wireless |
| Transmission Frequency | 868MHz |
| Transmission Security | AES-128 Encryption |
| Transmission Range (Free Space) | 1.2Km |
| Frequency Hopping | Support |
| Enrolling Method | Power up; Remote ID; QR Code |
| Electrical Characteristics |
| Typical Voltage | 3V |
| Power Supply | Battery powered |
| Battery Type | CR2450 x 1 |
| Standard Battery Life | Up to 3 years (standby time)
|
| General |
| Operation Temperature | -10°C to 55°C (14°F to 131°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Operation Humidity | 10% to 90% |
| IP Rate | IP66 |
| Dimension (WxHxD) | 62.4 mm x 62.4 mm x 14.6 mm |
| Weight | 85.5 g |
| Mounting Method | Wall; Surface |
| Application Scenario | Indoor standalone/with included probe
|
