Veracity
| POWER | |
| Power consumption | 1.3 watts via POE |
| POE STANDARDS | |
| PoE Standards | IEEE 802.3af POE (802.3at and 802.3bt compatible, but not required) Class 2 powered device No POE forwarding |
| ETHERNET INTERFACE | |
| Ethernet Interface | Two independently auto-configuring 10/100/1000 ports (10Base-T/100Base-TX/1000Base-T, half/full-duplex) Patch or crossover cables supported |
| LEDS | |
| Status indicators | Green LED - shows POE Power good/speed Green LED Blink = Power Good Green LED Flash = 10Base-T/100-BaseTX Green LED On = 1000Base-T Yellow LED - shows Ethernet link/activity |
| PHYSICAL/ENVIRONMENTAL | |
| Dimensions | L 105mm W 40mm H 22mm |
| Weight | 79g [2.8 oz] |
| Mounting | Two 5mm diameter mounting holes. Centres 111mm apart |
| Operating temperature | -40°C to 70°C [-40°F to 158°F] |
| Relative humidity | Up to 85%, non-condensing |
| Compliance | CE, FCC, RoHS, UKCA, UL |
