| Camera | |
| Image Sensor | 1/2.7" CMOS |
| Effective pixels | 5M |
| Maximum frame rate | 2560H x 1440V @30fps |
| Number of Lens | 4 |
| Focal length | 2.49mm |
| Aperture | 2.5 |
| Field of view | 140°( D ) , 111°( H ) , 85°( V ) |
| Output resolution | MJPG:4992*928@30ã€1920*1080@30ã€1280*720@30ã€640@360@30; YUY2:640*360 |
| Video format | MJPG/YUY2 |
| Features | Real-time Hyperstiching, 7 modes of video layout |
| Microphone | |
| Quantity | Built-in 4 array omnidirectional microphones |
| Signal to noise ratio | 65 dB |
| Pickup range | 5m (radius) |
| Pickup angle | 360° |
| Response frequency | 200Hz to 8 kHz |
| Features | AI Voice Tracking |
| Speaker | |
| Quantity | 1 |
| Rated power | 3W |
| Sound pressure level | 75dBSPL@1m,1kHz |
| Signal to noise ratio | =75 dB |
| Distortion | =5% |
| Cavity volume | 0.35L |
| Frequency response range | 200Hz to 15kHz |
| USB Features | |
| Operating System | Windows/Mac/Android/Linux |
| Hardware requirement | 2.4GHz Intel Core 2 Duo Processor or above| 2GB RAM or above |
| Colour System / Compression | YUY2/MJPG |
| USB | USB 2.0 |
| USB Audio | Build-in Mic & Speaker |
| UVC | 1.1 |
| Environmental Conditions | |
| Operation Temperature | 0„ƒ~40„ƒ |
| Operation Humidity | 10%~90%RH |
| Compatible Application | |
| Support Major VC Software | ZOOM, Microsoft® Teams, Google Meet, Google Hangouts, Cisco WebEx®, RingCentral, etc. |
| Panocam Studio Speciï¬cations | |
| Settings | Brightness, 3D De-Noise, Contract, Exposure, Flicker |
| Function | Auto Detection, Auto Tracking |
| Field of View Adjustment | FOV-Top: Vertical+ 45°Up/ -15°Down FOV-Middle: Vertical± 30° FOV-Down: Vertical+ 20°Up/ -40°down |
| Video Layout Selection | Compose Mode, Manual Mode, Body-ï¬t Mode, Grid Mode, Presentation Mode, Speaker Mode |
| Operating System | Win 10 or higher / Mac OS 10. 13 or higher (studio software) |
| Hardware Requirement | Minimum hardware： Intel 4th generation I5 above, RAM of 4GB above Macbook Pro(2013) above, with RAM of 4GB or above Recommended hardware： Intel 7th generation I5 above, RAM 4GB above Mac Mini I3 (2018) above, RAM 8GB above |
| Power | |
| power supply | 12V 1A |
| Maximum power consumption | < 8W |
| I/O ports | Buttons | Indicators | |
| DC IN | 1 |
| USB Type-C(USB2.0) | 1 |
| Mode Button | 1 (Video layout switch) |
| Soft Button | 1 (Mute/unmute) |
| Indicators | 8 (Sound Locator), 1 (Microphone status) |
| Physical Speciï¬cations | |
| Camera Dimension LxHxD | 67.6x67.5x182.3mm |
| 1pc Dimension (package)LxWxH | 235x165x91mm |
| 15pcs Dimension (package)LxWxH | 515x255x505mm |
| Net Weight | 450g |
| Package Contents | |
| Package Contents | UC-M40 Camera Power Adaptor USB Cable User Guide |
| Warranty | |
| Camera | 3 years |
| Accessories | 1 year |
