Detectors technical characteristics
Blue Wave technology
| Yes
|
Automatic sensitivity
| Yes
|
Digital temperature compensation
| Yes
|
Tamper protection
| Front and rear
|
Signal Strength Indicators (SSI)
| Yes
|
Enforcer two-way wireless technology
Signal Strength Indicators (SSI)
| Yes
|
Instant two way device control (ITDC)
| Yes
|
Pyronix high security two way wireless data encryption protocol (TDE)
| Yes
|
Pyronix intelligent jamming detection
| Yes
|
Programmable wireless supervision time
| Yes
|
868MHz transceiver FM technology
| Yes
|
One push to learn
| Yes
|
Transmission method
| Fully encrypted rolling code
|
Transmission range
| 1.6km in open space
|
Detectors technical characteristics
Maximum range
| 10m
|
Animal immunity
| 20kg
|
Detection zones
| 52
|
Detection planes
| 5
|
Mounting
Optimum coverage height
| 1.8 - 2.4m
|
Certified mounting height
| 1.8 - 2.4m
|
Environmental and operating features
Storage temperature
| -20C to 50C
|
Certified operating temperature
| -10C to 40C
|
Nominal operating temperature
| -10C to 50C
|
Physical dimensions (H x W x D)
| 117 x 69 x 50mm
|
Electrical & battery
Battery type
| 1 x CR123A
|
Battery life
| up to 2 years
|
Battery voltage
| 3.0V
|
Low battery threshold
| 2.5V +/- 5% at 25C
|
Certifications and warranty
Electrical conformity
| CE
|
EN Certificate
| EN50131-5-3: 2005 + A1: 2008, EN50130-4: 1995 + A1: 1998 + A2: 2003, EN61000-6-3: 2007
|
Certification type
| IMQ
|
Certificate number
| CA12.01426
|
Environmental class
| II
|
Warranty
| 2 years
|
Security Grade
| Grade 2
|
Pyronix
