Pyronix
| Communications and modems | |
| Signalling formats | Contact ID, Fast Format, SIA and SMS Supports voice calling functions and upload/downloading via InSite |
| Baud rate | 1200bps |
| Dimensions (W x H x D) | 109 X 56 X 13mm |
| Electrical & battery | |
| Voltage | ~12VDC |
| Quiescent current consumption | ~20mA |
| Maximum current consumption | ~40mA |
| Certifications and warranty | |
| Declaration of operation mode | Pass-through |
| Compliance | EN 61000-6-3:2007 + A1: 2011 EN 50130-4: 2011 EN 60950-1:2006 + A12: 2011 ETSI ES 203 021-1 V2.1.1/-2 V2.1.2/-3 V2.1.2 EN 50136-1: 2012 EN 50136-2: 2013 |
| ATS level | SP2 |
| Environmental class (EC) | II |
| Electrical conformity | CE |
| Warranty | 2 years |
| Documents |
|---|
