Veracity
| TIME SERVER | |
| Time source | GPS Satellite |
| Protocol | NTP Stratum 1 Time Server (NTPv4) |
| Accuracy | Ethernet NTP ± 1ms overall GPS source ±0.1μS |
| ANTENNA | |
| Connector | SMA Male |
| Cable | 5 metre cable, (optional 10 metre extension) |
| Antenna head | GPS sensor, in externally rated magnetic housing (+ adhesive pad/window fixing) |
| POWER | |
| Unit power | 1.5W |
| POE type | Class 1 |
| Alternative power input | 10-40V DC (max current 150mA at 12V) |
| ETHERNET INTERFACE | |
| Connector type | RJ45 |
| Rate | 10Base-T/100Base-TX full-duplex with auto-negotiation |
| Data security | Shared Keys system (server authentication) |
| LEDS | |
| Status indicators | Green LED: long pulse: OK - short pulse: no GPS lock Amber LED: heartbeat pulse |
| PHYSICAL/ENVIRONMENTAL | |
| Dimensions | L 87mm W 75mm H 22mm (W 97mm with wall mounting brackets) L 3.42 inches W 2.95 in H 0.86 in (W 3.8 in with wall mounting brackets) |
| Weight | 123g [ 4.3oz ] (with mounting brackets) 121g [4.2oz] (without brackets) |
| Operating temperature | TIMENET Pro -15oC to 75oC [5oF to 167oF] Antenna -40oC to 85oC [-40oF to 185oF] |
| Relative humidity | 95% non-condensing |
| Compliance | CE, FCC, UKCA, RoHS |
