Hikvision
| Display parameters | |
| Size | / |
| Operation method | / |
| Type | / |
| Video parameters | |
| Supplement light | IR supplement |
| Lens | Low Illumination 2 MP HD IR Camera |
| FOV | Horizontal: 180°, Vertical: 96° |
| Pixel | Main stream: 1920 x 1080 Sub stream: 720 x 480 |
| Audio parameters | |
| Audio quality | Noise suppression and echo cancellation |
| Capacity | |
| Linked indoor station | 500 |
| Sub door station capacity | 16 |
| Network parameters | |
| Communication protocol | TCP/IP, RTSP |
| Wired network | Support |
| Wi-Fi | / |
| Bluetooth | / |
| Device interfaces | |
| Network interface | 1 10/100M self-adaptive Ethernet |
| Exit button | 2 |
| Lock control | 2 |
| Door contact input | 2 |
| Power interface | 1 |
| General | |
| Button | / |
| Installation | Flush mounting, surface mounting |
| Indicator | / |
| Weight | Without package: 415 g With package: 625 g |
| Protective level | IP65 |
| Working temperature | -40° C to +55° C (-40° F to 131° F) |
| Working humidity | 10% to 95% |
| Dimensions | 98 mm x 99.8 mm x 43.9 mm (3.86" x 3.93" x 1.73") |
| Battery | / |
| Power supply | IEEE802.3af, standard PoE 12 VDC, 1 A |
| Application environment | Outdoor |
| Power consumption | 4 W |
| Language | English, French, Portuguese (Brazil), Spanish, Russian, German, Italian, polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Portuguese, Slovak |
