Hikvision iDS-7204HUHI-M1/PXT(STD)/4A+4/1ALM 4-Ch 8mp Turbo HD DVR AcuSense

Mouse over the image to zoom. Double-tap and hold to zoom.

Hikvision iDS-7204HUHI-M1/PXT(STD)/4A+4/1ALM 4-Ch 8mp Turbo HD DVR AcuSense

Product Code: ITM005768

UPC: 6942160408491

HDD Order Policy

Due to a shortage of HDDs:
• Orders of more than 10 HDDs in a single day will be automatically rejected.
• If the HDD quantity exceeds the total NVR/DVR quantity in the order, the order will also be automatically rejected.

Hikvision iDS-7204HUHI-M1/PXT/1TB 4CH 5 MP 1U H.265 ACUSENSE POC DVR, 001TB-01-S

Hikvision iDS-7204HUHI-M1/PXT/2TB 4CH 5 MP 1U H.265 ACUSENSE POC DVR, 002TB-01-S

Hikvision iDS-7204HUHI-M1/PXT/3TB 4CH 5 MP 1U H.265 ACUSENSE POC DVR, 003TB-01-S

Hikvision iDS-7204HUHI-M1/PXT/6TB 4CH 5 MP 1U H.265 ACUSENSE POC DVR, 006TB-01-S

Hikvision iDS-7204HUHI-M1/PXT/8TB 4CH 5 MP 1U H.265 ACUSENSE POC DVR, 008TB-01-S

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 004TB-01-T

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 002TB-01-W

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 001TB-01-W

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 003TB-01-W

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 004TB-01-W

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 006TB-01-W

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 008TB-01-W

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 002TB-01-T

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 006TB-01-T

4CH 5 MP 1U H.265 ACUSENSE POC DVR, 008TB-01-T

PoC Yes
Channels 4

Online Availability

1103

In stock

Specifications Resources

Facial Recognition
Face Picture LibraryUp to 16 face picture libraries
Face Picture Comparison
Face picture comparison, face picture search;

2-ch face picture comparison alarm (HD analog camera)

Perimeter Protection
Human/Vehicle AnalysisUp to 4-ch

Video and Audio
IP Video Input4-ch (up to 8-ch), each up to 8 MP
Analog Video Input
4-ch

BNC interface (1.0 Vp-p, 75 O), supporting coaxitron connection
PoC Camera InputSupport Hikvision PoC camera
HDMI Output
1-ch, 2K (2560 × 1440)/60Hz,

1920 × 1080/60Hz,

1280 × 1024/60Hz,

1280 × 720/60Hz

HDMI/VGA simultaneous output
VGA Output
1-ch, 1920 × 1080/60Hz,

1280 × 1024/60Hz,

1280 × 720/60Hz

HDMI/VGA simultaneous output
CVBS InputPAL/NTSC
CVBS Output
1-ch, BNC (1.0 Vp-p, 75 O),

resolution: PAL: 704 × 576, NTSC: 704 × 480
Synchronous Playback4-ch
HDTVI Input8 MP(3840 × 2160)@12/15 fps, 3K(2960 x 1665)@25/20 fps,3K(3328x1504)@20fps,2K(2304x1296)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
AHD Input5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
HDCVI Input8 MP(3840 × 2160)@12/15 fps, 3K(2880×1620)@20/25fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
Audio Output1-ch, RCA (Linear, 1 KO)
Audio Input4-ch, RCA (2.0 Vp-p, 1 KO),4-ch via coaxial cable
Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KO) (using the first audio input)

Recording
Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution
Main stream:

8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps

1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

*: 8 MP@8 fps is only available for channel 1, 8 MP Lite is only available for channel 2 to channel 4.

Sub-stream:

WD1/4CIF/CIF@25 fps (P)/30 fps (N)
Video Bitrate32 Kbps to 10 Mbps
Dual-streamSupport main stream or sub stream
Stream TypeVideo, Video & Audio
Audio CompressionG.711u
Audio Bitrate64 Kbps
