Hikvision
| Network Parameters | |
| Ports | 4 x 10/100 Mbps PoE port,2 x 10/100 Mbps RJ45 port |
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| High Priority Ports | Ports 1 to 2 |
| Forwarding Mode | Store-and-forward switching |
| Working Mode | Standard mode (default), Extend mode |
| MAC Address Table | 2 K |
| Switching Capacity | 1.2 Gbps |
| Packet Forwarding Rate | 0.8928 Mpps |
| Internal Cache | 768 Kbits |
| PoE Power Supply | |
| PoE Standard | Port 1: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt; Ports 2 to 4: IEEE 802.3af, IEEE 802.3at |
| PoE Power Pin | End-span: 1/2(-), 3/6(+) Mid-span: 4/5(+), 7/8(-) 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| PoE Port | Hi-PoE: Port 1, PoE: Ports 2 to 4 |
| Max. Port Power | Port 1: 60 W, Ports 2 to 4: 30 W |
| PoE Power Budget | 60 W |
| Software Function | |
| Device Maintenance | Support remote upgrade, default parameter restoration, logs viewing, and basic network parameter configuration. |
| Port Configuration | Support port rate configuration, flow control, and ports enabling. |
| General | |
| Shell | Metal material, IP40 |
| Net Weight | 0.245 kg (0.54 lb) |
| Gross Weight | 0.645 kg (1.42 lb) |
| Dimensions (W x H x D) | 145.00 mm x 25.60 mm x 68.45 mm (5.71'' x 1.00'' x 2.69'') |
| Operating Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 48 VDC, 1.35 A |
| Max. Power Consumption | 65 W |
| Power Consumption in Idle | 2 W |
| Approval | |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011 +A1: 2014, EN 55035: 2017); IC (ICES-003: Issue 6); RCM (AS/NZS CISPR 32: 2015) |
| Safety | UL (UL 60950-1); CB (IEC 60950-1:2005, AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition); CE-LVD (EN 60950-1: 2006 + A11: 2009 +A1: 2010+A12: 2011+A2: 2013, EN 62368-1: 2014+A11: 2017) |
| Chemistry | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006) |
