Hikvision
| Parameters | |
| Weight | Approx. 3.3 kg (7.3 lb.) |
| Material | Housing: Aluminum Alloy |
| Dimension | Battery Dimension: 236 x 154 x 80 mm (9.29" x 6.06\" x 3.15\") Package Dimension: 280 x 170 x 218 mm (11.02 x 6.69\" x 8.58\")" |
| Protection level | IP68 (1.5 m, 72 h) |
| Operating Conditions | Charging Condition: -20 °C to 45 °C (-4 °F to 113 °F) Discharging Condition: -20 °C to 60 °C (-4 °F to 140 °F) |
| Interface | 1 RS-485 (half duplex), Ø5.5 mm coaxial power plug, M8 aviation plug |
| Storage Conditions | -20 °C to 60 °C (-4 °F to 140 °F) |
| Battery Type | Lithium |
| Battery Voltage | 10.8 V |
| Capacity | 30 Ah |
| Max. Charging Voltage | 12.6 V |
| Battery Life | More than 500 cycles |
| Heater | Yes |
| Solar Power Controller | MPPT solar power controller Fully charged voltage: 12.6 VDC Max. output current: 8 A |
