The Hikvision DS-2CD2546G3-IZS2UY(2.8/4mm) is a professional IP Camera built for modern CCTV installations, with support up to 4 MP where specified. Designed for reliability and ease of integration, this IP Camera is suitable for a wide range of security applications.Features:• 4 MP Acusense Smart Hybrid Light Vari-focal Mini Dome Network Camera• 2.8/4mm in one lens, point vari -focal• Anti-corrosion design (NEMA 4X), more reliable• Excellent low illumination performance via Powered by DarkFighter• Crystal -clear audio with Arrayed Dual -Mic• Person and vehicle classification based on deep learning• Water and dust resistant (IP67) , vandal resistant (IK08)• Specification Camera Image Sensor 1/3" Progressive Scan CMOS• Max. Resolution 2688 × 1520• Min. Illumination Color: 0.001 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Shutter Time 1 s to 1/100 ,000 s• Day & Night IR cut filter Angle Adjustment Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360° Lens Lens Type Varifocal lens, motorized lens, 2.8 to 4 mm Focal Length & FOV 2.8 mm, horizontal FOV 99.3° , vertical FOV 54.8°, diagonal FOV 120.2° 4 mm, horizontal FOV 80.0° , vertical FOV 44.1°, diagonal FOV 94.0° Lens Mount Ø14• Iris Type Fixed Aperture F1.6 Depth of Field 2.8 mm: 1.1 m to 8 4 mm: 1.3 m to 8 DORI DORI 2.8 mm: D: 66.6 m , O: 26.4 m, R: 13.3 m , I: 6.7 m 4 mm: D: 79.2 m , O: 31.4 m , R: 15.8 m, I: 7.9 m Illuminator• Supplement Light Type IR Supplement Light Range Up to 30 m• Smart Supplement Light Yes• IR Wavelength 850 nm Video 50 Hz: Main Stream 25 fps (2688 × 1520, 1920 × 1080 , 1280 × 720) 60 Hz: 30 fps (2688 × 1520 , 1920 × 1080 , 1280 × 720) Sub-Stream 50 Hz: 25 fps (1280 × 720 , 640 × 480 , 640 × 360) 60 Hz: 30 fps (1280 × 720 , 640 × 480 , 640 × 360) 50 Hz: 10 fps (1920 × 1080 , 1280 × 720 , 640 × 480 , 640 × 360)• Third Stream 60 Hz: 10 fps (1920 × 1080 , 1280 × 720 , 640 × 480 , 640 × 360)• Third stream is supported under certain settings.• Main stream: H.265/H.264/H.264+/H.265+ ,• Video Compression Sub-stream: H.265/H.264/MJPEG ,• Third stream: H.265/H.264 ,• Third stream is supported under certain settings. Video Bit Rate 32 Kbps to 8 Mbps• H.264 Type Baseline Profi le, Main Profile , High Profile
