| Product Specifications | HAY-JB100 | HAY-JB150 | HAY-JB190 | HAY-JB240 | HAY-JB300 | HAY-JB380 |
| Size | 100x100x50mm | 150x110x70mm | 190x140x70mm | 240x190x90mm | 300x220x120mm | 380x300x120mm |
| Application | Ordinary Junctions | Ordinary Junctions | Ordinary Junctions | Ordinary Junctions | Ordinary Junctions | Ordinary Junctions |
| Material | ABS | ABS | ABS | ABS | ABS | ABS |
| Type of Material | Halogen -Free | Halogen -Free | Halogen -Free | Halogen -Free | Halogen -Free | Halogen -Free |
| IP Degree | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Insulation Class | II (according to IEC 61140) | II | II | II | II | II |
| Lid Screws No & Type | 4 - Metal | 4 - Metal | 4 - Metal | 4 - Metal | 4 - Metal | 4 - Metal |
| Documents |
|---|
