| Specifications | |
| Classification | Electro-optical radio channel security detector |
| Type of detector | Wireless |
| Installation method | Outdoors/indoors |
| Colour | White |
| Recommended installation height | 0.8 - 1.3 m |
| Compatibility | Operates with all Ajax hubs and range extenders |
| Sensing element | Two PIR sensors |
| Alarm signal delivery time | 0.15 s |
| Motion detection distance | Adjustable, up to 3-15 m |
| Detection angle | Horizontal - 90° |
| Time for motion detection | From 0.3 to 2 m/s |
| Sensitivity | Adjustable, 3 levels |
| Pet immunity | Weight - not relevant Height - up to 80 cm |
| Anti-sabotage | Anti-masking Protection against forgery Jamming detection Tamper-resistant |
| Power supply | Battery: 2 x CR123A batteries, 3 V, pre-installed Optional mains supply: 5€“28 V DC |
| Battery life | Up to 5 years |
| Jeweller radio technology | Communication range with central unit €” up to 1,700 m in an open space Two-way communication between devices Radio frequency bands: 866.0 €“ 866.5 MHz 868.0 €“ 868.6 MHz 868.7 €“ 869.2 MHz 905.0 €“ 926.5 MHz 915.85 €“ 926.5 MHz 921.0 €“ 922.0 MHz (depends on the region of sale) Self-adjusting RF output power €” up to 20 mW Block encryption based on AES algorithm Detector polling period €” 12ˆ’300 s |
| Temperature sensor | Available |
| Operating temperature range | From -25°Ð¡ to +60°Ð¡ |
| Permissible humidity | Up to 95% |
| Protection class | IP55 |
| Remote set up and testing | + |
| Dimensions | 183 x 70 x 65 mm |
| Weight | 322 g |
| Warranty | Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty. |
| Complete set | MotionProtect Outdoor motion detector SmartBracket mounting panel Two CR123A batteries (pre-installed) Installation kit User's guide |
